Life time warranty seal
Add your photo

Baffled Oil Catch Can, fits Ford Ranger 3.2L Diesel 2011+

Model
MMBCC-RGR-11BE
Sale Price $260.95 Regular Price $346.74
-
+
Add to Wish List

$Login or create an account to earn 260 pts on this product.
Key Features
Features
  • Direct fit for 2011+ Ford Ranger 3.2L Diesel
  • Durable 3mm thick steel bracket mounts the catch can out of the way of other engine components and isolates it from engine vibration for a lifetime of service
  • 221 ml capacity for longer service intervals
  • Synthetic filter captures carbon and other particulates
  • CNC-machined aluminum barbed fittings create a secure connection between lines and can
  • Includes direct-fit hoses for easy installation
  • Helps prevent carbon buildup on intake valves
  • Filter and can are fully serviceable
  • Mishimoto Lifetime Warranty

Installation Difficulty: Easy

Key Features
  • Direct fit for 2011+ Ford Ranger 3.2L Diesel
  • Durable 3mm thick steel bracket mounts the catch can out of the way of other engine components and isolates it from engine vibration for a lifetime of service
  • 221 ml capacity for longer service intervals
  • Synthetic filter captures carbon and other particulates
  • CNC-machined aluminum barbed fittings create a secure connection between lines and can
  • Includes direct-fit hoses for easy installation
  • Helps prevent carbon buildup on intake valves
  • Filter and can are fully serviceable
  • Mishimoto Lifetime Warranty

Product Description

The 2011+ Ford Ranger 3.2L diesel is one of the most capable small trucks on the planet. With its direct-injected and turbocharged diesel engine, 350 lb.-ft. of torque, the 2011+ Ranger is focused on combining efficiency with capability. The 3.2L Duratorq engine under the bonnet of the Ranger produces plenty of power to let you roam free, but the direct-injection that makes that power possible also places it at risk for carbon buildup. Blow-by is a natural occurrence in any internal-combustion engine, but direct-injected engines are particularly susceptible to the carbon buildup it can cause. Without fuel washing over the back of the engine's intake valves, blow-by is free to accumulate and the heat of combustion eventually turns that blow-by into hard carbon deposits. As those carbon deposits build up, they rob the 3.2L Duratorq of air, reducing power and fuel economy. If left completely unchecked, the carbon buildup can get so bad that the engine loses compression and begins to misfire. To help prevent these issues, Mishimoto has developed a direct-fit catch can kit for your 2011+ Ranger 3.2L Duratorq. Our catch can intercepts the blow-by, preventing it from entering the intake and coating the intake valves. The oil, fuel, and water vapor in the blow-by is condensed by our catch can's internal baffle and air diverters, while a high-flow synthetic filter on the outlet of the catch can removes carbon and other particulate. This system ensures that the only thing moving through your intake is clean air. As with all our direct-fit catch can kits, this 2011+ Ranger 3.2L diesel catch can kit comes with direct-fit lines and bracket that securely mounts the catch can without any cutting or drilling. Our 2011+ Ford Ranger 3.2L diesel catch can is also backed by our Mishimoto Lifetime Warranty for a lifetime of protection.
Read more

TECH SPECS

More Information
Applications 2011+ Ford Ranger XL w/ 3.2L Diesel
2011+ Ford Ranger XLS w/ 3.2L Diesel
2011+ Ford Ranger XLT w/ 3.2L Diesel
2011+ Ford Ranger FX4 w/ 3.2L Diesel
2011+ Ford Ranger Wildtrak w/ 3.2L Diesel
Engine Codes 3.2L Duratorq
Installation Notes 22 in-lbs (2.5NM) recommended for all worm-gear clamps. These clamps have an operating range of 18-27 in- 2-3NM. Do not exceed the maximum torque rating of 27 in-lbs (3NM).
Note After installation, Mishimoto recommends checking the contents of the baffled catch cans every 1,600 kilometers until a baseline is established. Oil blow-by accumulation will vary with ambient temperatures and driving conditions. It is important that the contents of the can do not rise above the internal baffle.

Purchase Includes

(1) Black, Anodized 6061 Aluminum 221ml Catch Can
(2) Steel Mounting Brackets
(2) Direct-Fit Oil Resistant Hoses
(2) CNC-Machined Aluminum Barbed Fittings
(4) Worm Gear Clamps
(1) High-Flow Filter
(1) Air Diverter
(1) Internal Baffle Rod
(1) 3/8-in NPT Plug
(1) Large O-Ring
(1) Zip Tie Tree Clip
Mounting Hardware
Mishimoto Lifetime Warranty

Note:

After installation, Mishimoto recommends checking the contents of the baffled catch cans every 1,600 kilometers until a baseline is established. Oil blow-by accumulation will vary with ambient temperatures and driving conditions. It is important that the contents of the can do not rise above the internal baffle.

Warranty

Mishimoto Automotive (“Mishimoto”) warrants its products under this lifetime limited warranty policy (“Warranty Policy”). This Warranty Policy applies solely to: (i) Mishimoto Products purchased directly from Mishimoto or Mishimoto authorized dealers (each a “Mishimoto Product” and collectively, the “Mishimoto Products”) and (ii) the original purchaser of such Mishimoto Product (“Purchaser”). This Warranty Policy is non-transferable and all claims under this Warranty Policy must be accompanied by the original sales receipt. The terms and conditions of this Warranty Policy are subject to change by Mishimoto at any time without notice.

For our complete warranty policy, please click here.
