Performance Aluminum Radiator, Fits Subaru WRX 2022+
Performance Aluminum Radiator, Fits Subaru WRX 2022+
- Direct fit for 2022+ Subaru WRX
- 32 percent increase in core volume over stock for improved cooling efficiency
- 50 percent greater fin surface area for improved heat transfer
- Two-row core balances optimal flow with cooling performance
- Precision TIG-welded end tanks resist vibration and impacts on the street, gravel, or dirt
- 36mm-thick core with louvered fins makes the most of air moving through the grille
- Slotted drain plug makes services mess-free
- Pair with MMHOSE-WRX-22 for the enhanced cooling performance
- Mishimoto Lifetime Warranty
Installation Difficulty: Medium
- Direct fit for 2022+ Subaru WRX
- 32 percent increase in core volume over stock for improved cooling efficiency
- 50 percent greater fin surface area for improved heat transfer
- Two-row core balances optimal flow with cooling performance
- Precision TIG-welded end tanks resist vibration and impacts on the street, gravel, or dirt
- 36mm-thick core with louvered fins makes the most of air moving through the grille
- Slotted drain plug makes services mess-free
- Pair with MMHOSE-WRX-22 for the enhanced cooling performance
- Mishimoto Lifetime Warranty
Product Description
Our radiator features aluminum end tanks that are precision TIG-welded to withstand the vibrations and impacts that rally, track, or everyday driving throw at it. To help keep your FA24 boxer engine cool for miles of wide-open-throttle, we've sandwiched a two-row, 36 mm-thick core between those end tanks. This core features densely packed and louvered fins that effectively circulate air throughout the core for maximum heat transfer. The larger core also translates to a 32% increase in core volume, meaning our radiator can pull more heat out of more coolant, for more efficient cooling. A slotted drain plug helps direct coolant into your drain pan, instead of onto the floor during service. Like all Mishimoto radiators, this 2022+ Subaru WRX performance aluminum radiator is backed by our Mishimoto Lifetime Warranty.
TECH SPECS
Overall Height (in) | 21.49 |
---|---|
Overall Length (in) | 29.41 |
Core Length (in) | 28 |
Core Height (in) | 15.75 |
Fluid Capacity (gal) | 0.978 |
Rows | 2 |
Inlet (in) | 1.65 |
Outlet (in) | 1.65 |
Core Thickness (in) | 1.42 |
Drain Plug Thread Size | M12x1.5 |
Applications | 2022+ Subaru WRX H4 2.4L Turbo |
Engine Codes | FA24DIT |
Chassis Codes | VB |
Coolant Capacity | 0.978 |
Compatible Vehicles
Purchase Includes
(1) M12x1.5 Slotted Drain Plug
(1) Mishimoto Radiator Cap
Mishimoto Lifetime Warranty
