Transmission Cooler, fits Chevrolet Silverado 1500 V8 2014-2018
Transmission Cooler, fits Chevrolet Silverado 1500 V8 2014-2018
MISHI POINTS INFO
Get exclusive points discounts ONLY for #TeamMishi Rewards Program account holders. Join to earn reward points on every dollar you spend at mishimoto.com. Click here for our terms and conditions.
- Fits all 2014-2018 Chevrolet Silverado and GMC Sierra 1500 V8
- Stacked-plate construction for maximum durability and superior cooling
- Adds an extra 0.65 quarts of transmission fluid and over 3,000 square-inches of cooling surface area
- Durable aluminum adapter lines and CNC-machined brackets make installation easy
- Includes ambient air temp sensor relocation bracket for 2014 models
- Included thermal bypass valve delete allows fluid flow to the cooler at all times for vehicles in hot climates
- Patent number D905,116
- Mishimoto Lifetime Warranty
Installation Difficulty: Medium
- Fits all 2014-2018 Chevrolet Silverado and GMC Sierra 1500 V8
- Stacked-plate construction for maximum durability and superior cooling
- Adds an extra 0.65 quarts of transmission fluid and over 3,000 square-inches of cooling surface area
- Durable aluminum adapter lines and CNC-machined brackets make installation easy
- Includes ambient air temp sensor relocation bracket for 2014 models
- Included thermal bypass valve delete allows fluid flow to the cooler at all times for vehicles in hot climates
- Patent number D905,116
- Mishimoto Lifetime Warranty
Product Description
Luckily, Mishimoto has developed a cooler to do just that. Our 2014-2018 Chevy Silverado/GMC Sierra 1500 V8 transmission cooler utilizes a stacked-plate design for maximum durability and powerful cooling. The Mishimoto transmission cooler mounts in line with the factory cooling system to add an extra 0.65 quarts of transmission fluid and over 3,000 square inches of surface area for a significant increase in cooling potential.
Included with the Mishimoto transmission cooler are adapter lines that connect directly to the stock cooling system and a relocation bracket for the ambient air temperature sensor. CNC-machined mounting brackets and high-grade transmission cooler hoses make installing this transmission cooler a breeze. Also provided with this kit is a thermal bypass valve delete that allows fluid to flow to the cooler at all times, making this cooler ideal for drivers in hot climates.
Like all Mishimoto products, our 2014-2018 Chevy Silverado/GMC Sierra 1500 V8 transmission cooler is backed by our Lifetime Warranty with Accident Protection for worry-free cooling as long as you own it.
TECH SPECS
| Rows | 14 |
|---|---|
| Core Length (in) | 27 |
| Core Height (in) | 6 |
| Core Thickness (in) | 1.25 |
| Applications | 2015+ Cadillac Escalade 6.2L V8 2015+ Cadillac Escalade 6.2L V8 2014-2018 Chevrolet Silverado 1500 5.3L V8 2014-2018 Chevrolet Silverado 1500 6.2L V8 2015+ Chevrolet Suburban 5.3L V8 2015+ Chevrolet Tahoe 5.3L V8 2014-2018 GMC Sierra 1500 5.3L V8 2014-2018 GMC Sierra 1500 6.2L V8 2015+ GMC Yukon 5.3L V8 2015+ GMC Yukon 6.2L V8 2015+ GMC Yukon XL 5.3L V8 2015+ GMC Yukon XL 6.2L V8 |
| Fluid Capacity (qts) | 0.65 |
| Note | Minor drilling is required to install the adapter lines for this cooler. Please see the included drilling template and installation instructions for a detailed guide. 2014 model year vehicles require relocation of the ambient air temperature sensor. Please see the included installation note card for detailed instructions. |
Compatible Vehicles
Installation Guides
Purchase Includes
High-Pressure Transmission Cooler Lines
High-Strength Aluminum Transmission Cooler Adapter Lines
Pre-Installed CNC-Machined Aluminum Mounting Brackets
CNC-Machined Aluminum Mounting Brackets
Removable Thermal Bypass Valve Delete
Ambient Air Temperature Sensor Relocation Bracket
Stick-On Drilling Template
Installation Note Card
Mounting Hardware
Mishimoto Lifetime Warranty
Note:
Minor drilling is required to install the adapter lines for this cooler. Please see the included drilling template and installation instructions for a detailed guide.2014 model year vehicles require relocation of the ambient air temperature sensor. Please see the included installation note card for detailed instructions.
Trying something new can be a daunting, especially when you're changing something you've done well for a long time. In the case of our 2014+ Chevy/GMC K2 transmission cooler, the design of the stock transmission cooler had us stepping off the beaten path in search of the best possible solution.
In our previous posts, we discussed the design of the stock cooler that's integrated with the A/C condenser and how we would be adding an external cooler to supplement it. We had our core (the same one that we used on our Duramax project) mounted behind the grille of our volunteer K2, but we had no way of getting transmission fluid. This is where we really
The second post in any of our project blogs is usually where we show you an aluminum box that represents the outer dimensions of our planned product. This time though, we're going rogue.
Sort of.
Our last post looked at the stock transmission cooler for Chevy/GMC's K2 chassis. To recap, the stock K2 transmission cooler is a bit of a chimera. If you were to look through the grille of a K2, you would never find the transmission cooler. Unlike other vehicles that have an obvious transmission cooler bolted onto the radiator, the K2 trans cooler is integrated into the truck's A/C condenser. Removing the A/C condenser from the vehicle doesn't make finding the transmission cooler any easier either. Only under close inspection can you see the break in the end-tank where the factory separated the two coolers. Otherwise, the A/C condenser and the transmission cooler share the similar tubes and fins, but
Back in the old days, if you wanted a vehicle for doing work on the farm, you bought a tractor and trailer. If you wanted luxury to go to your gala event, you had somebody build a coach and put an engine in it. If you just wanted to get to work, you bought a horse. On the off chance you were a wealthy farmer, who had another job in town, you had to buy them all.
Today, you can drive to work, the farm, and the Met Gala all in the same vehicle. And it smells at lot better than a horse.
Chevy/GMC's K2 platform of pickup trucks and SUVs is a combination of every vehicle you could ever need. The interior is plush and packed full of enough tech to satisfy a 17-year-old pop star. Order one in black or white and you'll have no trouble getting the valet to sprint to your door and accept your keys.
