Ford 7.3L Powerstroke Transmission Cooler, 1999–2003

Ford 7.3L Powerstroke Transmission Cooler, 1999–2003
Ford 7.3L Powerstroke Transmission Cooler, 1999–2003
Ford 7.3L Powerstroke Transmission Cooler, 1999–2003
Ford 7.3L Powerstroke Transmission Cooler, 1999–2003

Regular Price: $410.59

Sale Price $349.95


Bread Checkout
Installation Difficulty

  • Direct fit for the 1999–2003 Ford 7.3L Powerstroke
  • Proven +10°F (+5.6°C) drop in transmission fluid temperature with no additional fluid pressure drop
  • No modification necessary for installation, functions with all stock equipment
  • 37-row stacked-plate fluid cooler provides larger surface area over the stock 9-row transmission cooler
  • Transmission cooler core has a 265% increase in core volume compared to the factory 9-row transmission cooler
  • Increases transmission fluid capacity by 1.0 qt
  • Mishimoto Lifetime Warranty

Heavy loads are no match for a 1999–2003 7.3L Powerstroke equipped with the Mishimoto 7.3L Transmission Cooler. The stock 7.3L Powerstroke transmission cooler can come up short of providing sufficient cooling, and with more weight in the truck bed, transmission temperatures tend to rise. Avoid those high temperatures and complement your cooling system with the latest addition to Mishimoto’s 7.3L Powerstroke performance parts, the all-new 7.3L transmission cooler.

With the Mishimoto 7.3L Transmission Cooler, high transmission fluid temperatures will be the least of your worries. The 37-row Mishimoto stacked-plate cooler provides a larger surface area over both of the stock coolers. Core volume is increased by a whopping 265%, and fluid capacity is increased by 1.0 qt. The increased size of this 7.3L transmission cooler provides a proven+10°F drop in transmission fluid temperature.

No modifications are necessary for installation, and just like all Mishimoto 7.3L Powerstroke parts, this cooler comes with the Mishimoto Lifetime Warranty.

Mishimoto Automotive (“Mishimoto”) warrants its products under this lifetime limited warranty policy (“Warranty Policy”). This Warranty Policy applies solely to: (i) Mishimoto Products purchased directly from Mishimoto or Mishimoto authorized dealers (each a “Mishimoto Product” and collectively, the “Mishimoto Products”) and (ii) the original purchaser of such Mishimoto Product (“Purchaser”). This Warranty Policy is non-transferable and all claims under this Warranty Policy must be accompanied by the original sales receipt. The terms and conditions of this Warranty Policy are subject to change by Mishimoto at any time without notice.

For our complete warranty policy, please click here.




Material 6061 Aluminum

Core Height 16.13"

Rows 37

Note Recall Notice: There is currently a recall in effect for the transmission cooler lines included in this kit. If you purchased this kit (MMTC-F2D-99SL) before 04/04/2018 please click here to contact our customer service team and order replacement lines at no cost.

Vehicles equipped with a high mounted power steering cooler will need to have the power steering cooler relocated to the lower mounting location.

May not be a direct fit for vehicles built before 12/08/1998 due to additional bracing.

Core Thickness 1.25" (32 mm)

Core Length 25.25"

Tank Wall Thickness .08" (2 mm)

Increase In Oil Capacity 1.0 qt

Temp Difference +10°F (+5.6°C) drop in transmission fluid temperature

Overall Height 23.5"

Overall Length 34"

Overall Width 1.34" (34 mm)

Core Size 25.25" x 16.13" x 1.25" (642 mm x 410 mm x 32 mm)

Inlet .5" (13 mm)

Outlet .5" (13 mm)

Purchase Includes (1) Mishimoto Stacked-Plate Transmission Cooler
(2) High-Pressure Transmission Lines
(4) Worm Gear Clamps
Mounting Hardware
Mishimoto Lifetime Warranty

Also Fits 1999–2003 Ford F-250 w/ 7.3L Powerstroke
1999–2003 Ford F-350 w/ 7.3L Powerstroke
1999–2003 Ford F-450 w/ 7.3L Powerstroke

Braided Hoses False
