Ford F-150 3.5L EcoBoost Baffled Oil Catch Can, 2017+

Ford F-150 3.5L EcoBoost Baffled Oil Catch Can, 2017+
Ford F-150 3.5L EcoBoost Baffled Oil Catch Can, 2017+
Ford F-150 3.5L EcoBoost Baffled Oil Catch Can, 2017+
Ford F-150 3.5L EcoBoost Baffled Oil Catch Can, 2017+

Regular Price: $579.93

Sale Price $434.95

Bread Checkout
Installation Difficulty

  • Direct fit for 2017+ Ford F-150 3.5L EcoBoost
  • Dual-can setup captures blow-by from both the PCV and CCV systems
  • Includes oversized 12 fl. oz. can for longer service intervals
  • CCV side accommodates stock pressure sensor for CEL-free running
  • Application-specific lines fit with stock engine cover
  • 3mm-thick steel bracket won’t bend, rattle, or break under heavy abuse
  • Includes stock-style quick-disconnect fittings
  • Filters and cans are fully serviceable
  • Mishimoto Lifetime Warranty

Turbocharging and direct-injection are quickly becoming the go-to method for building powerful and efficient trucks. However, if not carefully maintained, they can also mean the end for your 2017+ Ford F-150 3.5L EcoBoost.

Direct injection makes the 3.5L EcoBoost one of the most efficient engines ever fitted to the F-150. But, without the benefit of fuel washing over the back of the intake valves, blow-by is free to accumulate in the form of carbon deposits. Eventually, those carbon deposits can choke your engine and reduce its performance. Thankfully, Mishimoto has a solution.

Mishimoto's 2017+ Ford F-150 3.5L EcoBoost Catch Can Kit protects your intake tract and valves from the harmful effects of blow-by and carbon accumulation. The dual-can setup ensures that blow-by is routed away from your intake and valves in all driving conditions. Our road-proven 12 fl. oz. baffled catch can holds more blow-by for extended service intervals. Whether you're hard on the throttle or cruising around town, these cans have your engine's back.

The powder coated, 3mm-thick steel bracket is strong enough to handle any terrain a work truck or daily driver will see, and the pre-installed quick-disconnect fittings make installation a breeze. Of course, this catch can kit is backed by our Mishimoto Lifetime Warranty so you can rest easy knowing your 2017+ F-150 3.5L EcoBoost is protected from blow-by for as long as you own it.

Mishimoto Automotive (“Mishimoto”) warrants its products under this lifetime limited warranty policy (“Warranty Policy”). This Warranty Policy applies solely to: (i) Mishimoto Products purchased directly from Mishimoto or Mishimoto authorized dealers (each a “Mishimoto Product” and collectively, the “Mishimoto Products”) and (ii) the original purchaser of such Mishimoto Product (“Purchaser”). This Warranty Policy is non-transferable and all claims under this Warranty Policy must be accompanied by the original sales receipt. The terms and conditions of this Warranty Policy are subject to change by Mishimoto at any time without notice.

For our complete warranty policy, please click here.



Inlet M16 x 1.5

Outlet M16 x 1.5

Drain Plug Thread Size 3/8" NPT

Capacity Large Can: 12 fl oz
Small Can: 3 fl oz

Purchase Includes (1) Application-Specific Mounting Bracket
(1) 12 fl oz Black, Anodized 6061 Aluminum Catch Can
(1) 3 fl oz Black, Anodized 6061 Aluminum Catch Can
(5) Direct-Fit Hoses
(4) Pre-Installed Quick-Disconnect Fittings
(4) CNC-Machined Aluminum Barbed Fittings
(2) Bronze Filters
(2) Air Diverters
(2) Internal Baffle & Rods
(2) 3/8" NPT Plugs
(2) Large O-Rings
(6) Worm Gear Clamps
Mounting Hardware
Mishimoto Lifetime Warranty

Fits 2017+ Ford F-150 3.5L EcoBoost
2017+ Ford Raptor 3.5L EcoBoost

Engine Codes 3.5L EcoBoost

Material 6061 Aluminum

Install Torque Specs 22 in-lbs (2.5N*M) recommended for all worm-gear clamps. These clamps have an operating range of 18-27 in-lbs 2-3N*M. Do not exceed the maximum torque rating of 27 in-lbs (3N*M).

Note After installation, Mishimoto recommends checking the contents of the baffled catch cans every 1,000 miles until a baseline is established. Oil blow-by accumulation will vary with ambient temperatures and driving conditions. It is important that the contents of the can do not rise above the internal baffle.
