Overall Height 3.8"
Overall Diameter 2.5"
Drain Plug Thread Size
3 fl oz.
(1) Compact Baffled Oil Catch Can
(1) Application-Specific Mounting Bracket
(2) Direct-Fit Hoses with Integrated Check Valve
(4) Spring Clamps
(2) 3/8" Aluminum Barbed Fittings
Mishimoto Lifetime Warranty
2018+ Honda Accord 2.0T
Install Torque Specs
22 in-lbs (2.5N*M) recommended for all worm-gear clamps. These clamps have an operating range of 18-27 in-lbs 2-3N*M. Do not exceed the maximum torque rating of 27 in-lbs (3N*M).
After installation, Mishimoto recommends checking the contents of the baffled catch can every 1,000 miles until a baseline is established. Oil blow-by accumulation will vary with ambient temperatures and driving conditions. It is important that the contents of the can do not rise above the internal baffle.
