Honda Civic Type R Performance Intercooler Kit, 2017+

Regular Price: $1,313.00

Sale Price $1,050.95

Bread Checkout

Installation Difficulty

  • Patent Pending
  • Direct fit for the 2017+ Honda Civic Type R
  • 4.7" thick intercooler design optimized for maximum flow
  • Max power gains of up to 10 whp and 10 wtq
  • Drops outlet air temperatures by 50°F on stock tuning
  • Optimal core design for maximum cooling efficiency with minimal pressure drop
  • Intercooler volume increased by 169% and external fin surface area by 189%
  • 2.5" piping diameter improves flow characteristics
  • Mandrel-bent aluminum cold-side piping for increased durability
  • Available in silver or black intercooler with the option of wrinkle black or wrinkle Rallye Red piping
  • Mishimoto Lifetime Warranty

It’s no easy feat to be dubbed as one of the fastest front-wheel drive production cars in the world. Honda put all of their engineering prowess behind this achievement, but since the 2017+ Honda Civic Type R finds itself in the gray area of track fiend and commuter car, some sacrifices had to be made. One of those sacrifices comes in the form of the underperforming intercooling system. Under intense driving conditions or just being caught in a sweltering summer day, the stock tube-and-fin intercooler soaks with heat, quelling the performance of your CTR.

We here at Mishimoto aim to put that power back into your hot-Honda by keeping it cool with the Mishimoto 2017+ Honda Civic Type R Performance Intercooler Kit. We started by increasing the overall size of the core to more than double that of the stock dimensions. The 4.7-inch thick core boasts a 169% increase in overall volume and bumps the external fin surface area by 189% for optimal heat rejection properties.

We didn’t stop with the size increase either. To keep the charged air flowing properly through the larger core, we updated to a bar-and-plate core construction. The robust design offers not only improved flow characteristics but also aids in transferring heat away from the charged air. The plastic end tanks are a thing of the past and have been replaced with our sleek cast aluminum designs to more effectively direct airflow to and from the piping.

With the Mishimoto Performance Intercooler Kit, the intercooler isn’t the only component that received an update. We took the liberty of overhauling the entire intercooling system. Honda carried some of those sacrifices in the name of mass production over to the intercooler piping as well. The restrictive piping diameters limit the K20C1’s potential to turn up the boost with tunes, and the rubber sections are destined to deteriorate down the line. We updated these charged air channels with a 2.5” mandrel-bent aluminum cold-side pipe. The rubber sections, including the hot-side pipe, were swapped for 5 layers of heat-resistant silicone. Both characteristics will increase the airflow through the system and make sure you never experience a boost leak.

The Mishimoto 2017+ Honda Civic Type R Performance Intercooler Kit comes with either a black or silver intercooler, with the option of wrinkle black or wrinkle red piping to match your style. This kit also includes the Mishimoto Lifetime Warranty to keep you boosting around the track worry free.

Mishimoto Automotive (“Mishimoto”) warrants its products under this lifetime limited warranty policy (“Warranty Policy”). This Warranty Policy applies solely to: (i) Mishimoto Products purchased directly from Mishimoto or Mishimoto authorized dealers (each a “Mishimoto Product” and collectively, the “Mishimoto Products”) and (ii) the original purchaser of such Mishimoto Product (“Purchaser”). This Warranty Policy is non-transferable and all claims under this Warranty Policy must be accompanied by the original sales receipt. The terms and conditions of this Warranty Policy are subject to change by Mishimoto at any time without notice.

For our complete warranty policy, please click here.

EVEN MORE COOL ITEMS

TECH SPECS

Installation Torque Specs 27 in-lbs (3N*M) recommended for all t-bolt and constant tension t-bolt clamps. These clamps have an operating range of 18-35 in-lbs (2-4N*M). Do not exceed the maximum torque rating of 35 in-lbs (4N*M).

Purchase Includes (1) Intercooler
(1) Mandrel-Bent Aluminum Cold-Side Pipe
(1) Silicone Hot-Side Pipe
(2) Silicone Couplers
(6) High-Torque Worm Gear Clamps
Mounting Hardware
Mishimoto Lifetime Warrany

Cold-Side Intercooler Pipe Specs 2.5"

Hot-Side Intercooler Pipe Specs 2.5"

Engine Codes K20C1

Chassis Codes FK8

Fits 2017+ Honda Civic Type R

Weight 29 lbs

Coating Powder Coated

Outlet 2.5"

Inlet 2.5"

Core Size 28" x 7.6" x 4.7"

Construction Bar-and-Plate

Engineering Blog

InterCOOLactic Planetary – 2017+ Honda Civic Type R Performance Intercooler Kit R&D, Part 6 – Dyno Testing Results

InterCOOLactic Planetary – 2017+ Honda Civic Type R Performance Intercooler Kit R&D, Part 6 – Dyno Testing Results

May 22, 2018

Investing in an intercooler shows some similarities to going to college. Hear me out. When that acceptance letter arrives, it’s understood that there’s a lot of money about to be spent as a down payment on the future. Some of us might have held a job or two while in school, but the general idea … Continue reading InterCOOLactic Planetary – 2017+ Honda Civic Type R Performance Intercooler Kit R&D, Part 6 – Dyno Testing Results →

Read More

InterCOOLactic Planetary – 2017+ Honda Civic Type R Performance Intercooler Kit R&D, Part 5 – Piping Production Sample

InterCOOLactic Planetary – 2017+ Honda Civic Type R Performance Intercooler Kit R&D, Part 5 – Piping Production Sample

April 05, 2018

It goes without saying that the intercooling system is an integral part of any turbocharged vehicle. What’s the sense of trying to cram more air into the cylinders if it can’t be compressed that easily. In fact, that almost defeats the entire point of having a turbo installed on your engine. For those of you … Continue reading InterCOOLactic Planetary – 2017+ Honda Civic Type R Performance Intercooler Kit R&D, Part 5 – Piping Production Sample →

Read More

InterCOOLactic Planetary – 2017+ Honda Civic Type R Performance Intercooler Kit R&D Part 4 – Intercooler Production Sample

InterCOOLactic Planetary – 2017+ Honda Civic Type R Performance Intercooler Kit R&D Part 4 – Intercooler Production Sample

March 29, 2018

When it comes to shopping for an upgraded intercooler, the first thing any of us look for is the temperature drop figure. For our new design, that information has still yet to come. For now, we’ll focus on the next most interesting specification, which, naturally, is the size of the core. In the case of … Continue reading InterCOOLactic Planetary – 2017+ Honda Civic Type R Performance Intercooler Kit R&D Part 4 – Intercooler Production Sample →

Read More
