Key Features
Features
Direct fit for 2007-2011 Jeep Wrangler JK
19-row bar-and-plate oil cooler for efficient cooling
Reduces transmission fluid temperatures to prevent damage and reduce wear
Includes brackets for easy installation
Includes lines and fittings for leak-free performance
The Jeep JK is known to experience high transmission fluid temperatures, especially when off-roading or driving in hot climates.Mishimoto has developed an ideal upgrade for reducing temperatures with our direct-fit transmission cooler kit, engineered specifically for the JK chassis.This kit uses precision-engineered brackets to mount a large 19-row cooler in the front grille area, thus maximizing airflow and providing significant increases in cooling efficiency.This kIt'significantly reduces transmission fluid temperatures, resulting in decreased transmission wear and improved vehicle safety.The Mishimoto Jeep JK Transmission Cooler Kit includes all lines and hardware necessary for an easy installation.This kit is a perfect complement to the Mishimoto Jeep JK oil cooler kit and the Mishimoto all-aluminum radiator for the ultimate cooling solution for your Jeep JK.As with all our products, this kit includes the Mishimoto lifetime warranty.
Read more
TECH SPECS
More Information
Rows
19
Core Length (in)
11
Core Height (in)
5.43
Core Thickness (in)
1.97
Engine Codes
EGH
Chassis Codes
JK
Installation Notes
22 in-lbs recommended for all worm-gear clamps. These clamps have an operating range of 18-27 in- 2-3NM. Do not exceed the maximum torque rating of 27 in-lbs Recommended torque specification for all straight fittings and banjo bolts: 15-25 lb-ft. Do not exceed the maximum torque rating of 35 ft-lb.
Caution
It is the installer's responsibility to check all thermostat plugs, NPT plugs, line fittings, and other connections to assure they are fully tightened before operating the vehicle. Mishimoto recommends that you check all connections at regular intervals, especially during the first few miles after installation. For additional technical information, contact our customer experience team.
Whether you're hauling a heavy trailer through the mountains or crawling over rocks in 4WD low, your truck’s transmission is under constant stress—and that stress generates heat. Lots of it. Left unchecked, heat is one of the fastest ways to wear down a transmission. That’s where a transmission cooler steps in. So, what does a transmission cooler actually do, and why might it be time to consider replacing or upgrading one?
An automatic transmission operates by using hydraulic fluid to transfer power, control gear changes, and lubricate internal components. Every time your truck shifts, tows, climbs, or even just idles in traffic, that fluid
