Performance Intercooler Kit, fits Kia Stinger GT 3.3T 2018+
MISHI POINTS INFO
Get exclusive points discounts ONLY for #TeamMishi Rewards Program account holders. Join to earn reward points on every dollar you spend at mishimoto.com. Click here for our terms and conditions.
- Direct fit for the 2018+ Kia Stinger GT 3.3T
- Includes performance intercooler, piping, cast aluminum merge manifold, and couplers for optimal flow and performance
- Drops intercooler outlet temperature by 29F on stock tune and 41F on stage 1 tune
- Max power gains of 8 whp and 8 wtq on stock tune with an additional 6 whp and 8 wtq on top of stage 1 tuning
- 94-percent increase in intercooler core volume
- 74-percent increase in external fin surface area
- 51-percent increase in flow through piping merger manifold
- 3-in intercooler piping for increased flow
- Additional bung incorporated on the cold-side intercooler pipe that can be drilled and tapped for methanol injection or sensors
- Compatible with stock recirculation valves
Installation Difficulty: Medium
CARB EO#: D-759-15 - Direct fit for the 2018+ Kia Stinger GT 3.3T
- Includes performance intercooler, piping, cast aluminum merge manifold, and couplers for optimal flow and performance
- Drops intercooler outlet temperature by 29F on stock tune and 41F on stage 1 tune
- Max power gains of 8 whp and 8 wtq on stock tune with an additional 6 whp and 8 wtq on top of stage 1 tuning
- 94-percent increase in intercooler core volume
- 74-percent increase in external fin surface area
- 51-percent increase in flow through piping merger manifold
- 3-in intercooler piping for increased flow
- Additional bung incorporated on the cold-side intercooler pipe that can be drilled and tapped for methanol injection or sensors
- Compatible with stock recirculation valves
Product Description
Our new design replaces the entire intercooling system, from turbo to throttle body, providing an optimized airflow to, from, and through the intercooler. The Mishimoto Performance Intercooler replaces the tube-and-fin core coupled to plastic end tanks with a robust bar-and-plate core, TIG-welded to a pair of cast aluminum end tanks for vastly improved heat dissipation and flow through the core. The construction wasn't the only update, and we also expanded our core for a 94% increase in core volume and a 74% increase in external fin surface area.
While the stock piping was already a durable aluminum construction, the diameter could lend itself to restrictions as the power increases. We kept the aluminum but increased the inner diameter to 3" for increased flow through the system with minimal pressure drop. We also made sure to overhaul the piping merger manifold, increasing the inlets to 2" and outlet to 3" for a 51% boost in flow straight out of the turbos, while retaining compatibility with the stock recirculation valves. Our piping kit is finished in a sleek micro-wrinkle black powder coat to retain the OEM+ look under the hood and is linked together with our 5-layer silicone couplers.
Our intercooler kit isn't just about a new look but will perform. Once on the dyno, the combination of the larger piping diameters, and increased intercooler size equated to a 29°F drop in outlet temperatures with a gain of 8whp and 8wtq on stock tuning. We also made sure to turn up the boost with our testing and installed a stage 1 map tune on our Stinger and recorded a 41°F drop in outlet temperature with a 6whp and 8wtq gain on top of the tune. The 2018+ Mishimoto Kia Stinger GT 3.3T Performance Intercooler Kit is available in silver or black intercooler color option and includes the Mishimoto Lifetime Warranty for a worry-free installation.
TECH SPECS
| Applications | 2018+ Kia Singer GT 2018+ Genesis G70 3.3T |
|---|---|
| Engine Codes | Lambda II GDI |
| Chassis Codes | CK |
| Note | Installation of this kit requires permanent modification to the front air guide shrouding, part number 29135-J5000. |
| Overall Length (in) | 38.7 |
| Overall Height (in) | 7.9 |
| Overall Width (in) | 8.1 |
| Core Type | Bar-and-Plate |
| Inlet (in) | 3 |
| Outlet (in) | 3 |
Downloads
Purchase Includes
(1) Hot-Side Piping Merger Manifold
(1) Hot-Side Intercooler Pipe
(1) Cold-Side Intercooler Pipe
(6) Silicone Couplers
(2) Application-Specific Mounting Brackets
(2) Air Diverters
(4) Mounting Grommets
(8) Heavy-Duty Worm Gear Clamps
Mounting Hardware
Mishimoto Lifetime Warranty
Note:
Installation of this kit requires permanent modification to the front air guide shrouding, part number 29135-J5000.Kia has made their big splash in the automotive industry with the Stinger's launch, and we wanted to make sure that we made ours right along with them. We've been looking for the perfect stone to chuck into this transcendental pond and we've finally found it, coincidentally in the shape of a massive intercooler. Since we've already reviewed the physical details of our new design in the last post, let's dive right into the testing.
Dyno-mite
Cooling power is key for the intercooling system, especially once the boost gets turned up. I can only assume you're here to see how this kit performs under pressure, so we strapped our Stinger up to our Dynapack system for a torture test in the name of science. Our testing consisted of two stages in order to get a good look at just how well our intercooler kit performs against the stock unit.
Kia is just the latest manufacturer to add the symphony turbocharging to their line of vehicles with the whirring and hissing duo attached to the Lambda II GDI engine powering the 2018+ Stinger GT. With the addition of these mechanical snails to Kia's repertoire, it's not much of a surprise that enthusiasts want to crank up the boost. And while it's imperative to improve the capacity of the intercooling system when tuning the Stinger, it's just as important to ensure it can handle the extra PSI. Specifically, the recirculation valve system needs to be up to snuff.
Luckily, the engineers here at Mishimoto have already been cooking up the means to adapt a more robust blow-off or recirculation valve of your choosing, but before we dive into that, let's take a quick look at why bypass valves are so important. For a more in-depth look, make sure you head to our technical post on blow-off valves.
Reduce, ReUse, Re-PSSSHT
Unfortunately for us, Bluetooth intercooling hasn't been invented yet. So when it came to updating and rerouting the intercooler's end tanks, we still needed a physical channel for the charged air to pass through. Put simply, it's not just the intercooler getting the overhaul, it's the entire system. This means more work for us, but you get to reap the benefits.
Kia's engineers already equipped the Stinger GT with one of the most robust intercooler piping systems that we've ever seen here in the Mishimoto R&D facility. What that meant for our engineer was that they gave us a sturdy foundation to build from. You already saw a preview of what we had in mind for the piping, but now the real deal
The splash has been made, and those ripples have finally made their way to shore. The proverbial pond that is the auto industry is a big one, but it's now time to see the end result of our big plans for the Stinger GT's intercooler upgrade.
There are a few aspects that the Stinger came up short on when it was released into the wild, and we saw the intercooler being a weak link. Given its design, it wouldn't be able to keep intake air temperatures at an appropriate level after some thrashing and turning up the boost. We last left you with the outline of the new intercooler, but now it's time for the real deal.
Metamorphosized
Just as Kia emerged from its cocoon with the Stinger, our intercooler is also finalizing its metamorphosis as
Like the Stinger's launch, we're also making our own sizable splash and causing some ripples with our intercooler kit. In case you haven't caught up on your Mishimoto Stinger news, our plan for keeping intake air temperatures down in the Stinger GT means a much larger, much more streamlined intercooler design. The intercooler might be playing a significant role, but it still needs the supporting cast.
Enter the new and improved Mishimoto intercooler piping kit. While it's still in the planning phase, these bits of 3D printed plastic are the physical manifestation of the models on our engineer's work station, and the ones we can use for testing the fitment. Let's dive into the specifics of each piece.
It's almost against the laws of nature to see a calm, serene pond and not want to throw rocks in it. I'm sure you get where I'm coming from. In this case, that pond is the proverbial state of the luxury sedan market, and here comes Kia with the biggest rock that it can find. That rock, the Stinger GT.
Where the Stinger made a big splash on its own, we want to make sure the ripples make their way around the pond. Basically, the Stinger rolled off the assembly line with some serious potential, but there's still room to grow, specifically when it comes to the intercooling system.
As we covered in our last post, the Stinger's stock
It might be old news by now, but we're all still getting acquainted with the fact that Kia, in tandem with Hyundai (who's also bringing their posh baby cousin Genesis along for the ride), have established a much more respectable position in the automotive community. The launch of the Stinger GT helped Kia break out of its chrysalis state not as a run of the mill butterfly, but more like a mantis that's snatching those fluttering insects out of the sky.
As we went over in the introduction to our Stinger, the secret to this vehicle's success is the silky-smooth Lambda II 3.3T coupled with the intuitive 8-speed automatic transmission. Even given Kia's advancements worthy of contending with those luxurious German counterparts, the Stinger does have some drawbacks that could hinder
