  • Complete kit includes all parts, wiring, and hardware required for installation
  • Moves radiator and heat exchanger to the rear of the vehicle
  • Prevents overheating issues by eliminating the potential for mud and debris to clog your radiator
  • Keeps radiator and heat exchanger safe from damage caused by rocks, trail debris, and mud
  • Custom-bent hard line coolant passage tubes make for a safe and secure, perfect fit installation
  • Includes aluminum dual pass radiator and heat exchanger with 16-inch high-flow fan for added cooling
  • Included LED backlit toggle switch for manual fan override matches factory dash lighting
  • Perfect upgrade for your RZR XP Turbo whether you’re racing, mud bogging, or rock crawling
  • Cooler passenger compartment with no hot air flowing in from a front-mounted radiator
  • 100-percent brazed aluminum core
  • TIG-welded to perfection
  • Mishimoto Lifetime Warranty


Whether you are racing, trail blazing, mud bogging, or rock crawling, one of the most common problems for the 2016+ Polaris RZR XP Turbo is overheating caused by the mounting location of the stock radiator and heat exchanger. The factory front-mounted position allows mud to clog the radiator and heat exchanger and leaves them vulnerable to damage from rocks, debris, and obstacles you may face on the trail.

To combat these challenges, we tasked our Mishimoto engineers with developing a system that would eliminate the all-too-common overheating issues, protect the cooling components from damage, and improve overall cooling in all conditions. And they delivered. The Mishimoto Radiator and Heat Exchange Relocation Kit for the Polaris RZR XP Turbo 2016+ accomplishes this by moving the cooling components to the rear of the vehicle, upgrading the radiator and heat exchanger, and adding a heavy-duty high-flow fan. This positioning allows for maximum airflow and keeps components out of harm’s way. But in true Mishimoto fashion, we didn’t stop there.

Our kit is complete with everything needed to upgrade and relocate your cooling system, including an aluminum dual pass radiator, aluminum dual pass heat exchanger, aluminum overflow tank, heavy-duty 16-inch high-flow fan with aluminum shroud, custom-bent hard line coolant passage tubes, Thermoformed ABS center console cover, fan controller and wiring harness, illuminated manual fan override toggle switch, and all hardware and brackets. All of these things combined provide the ultimate cooling for your Polaris RZR XP Turbo and a perfect, should-have-been-this-way-from-the-factory fit.

Like all our products, the Mishimoto Radiator and Intercooler Relocation Kit, Polaris RZR XP Turbo 2016+ is backed by our Mishimoto Lifetime Warranty.

Purchase Includes

Mishimoto Performance Aluminum Primary Radiator
Mishimoto Performance Aluminum Secondary Radiator
Mishimoto Overflow Tank
Mishimoto HD 16-inch-inch Fan
Aluminum Fan Shroud
(4) Custom fit hard pipes
(8) Hoses
(31) Worm Gear Clamps
(3) Spring Clamps
Thermoformed ABS center console cover
Fan controller
Illuminated manual fan override switch
Wiring harness
Mounting Brackets
Installation Hardware
Installation Guide
Mishimoto Lifetime Warranty


Removing stock fan from vehicle may cause a check engine light

More Information
Overall Height (in)19.73
Overall Length (in)27.44
Overall Width (in)7.18
Core Length (in)23.42
Core Height (in)15.98
Inlet (in)1
Outlet (in)1
Core Thickness (in)1.26
ApplicationsPolaris RZR XP Turbo 2016+

Removing stock fan from vehicle may cause a check engine light
