Baffled Oil Catch Can, PCV Side, fits Ford Mustang GT 2018-2023
Baffled Oil Catch Can, PCV Side, fits Ford Mustang GT 2018-2023
MISHI POINTS INFO
Get exclusive points discounts ONLY for #TeamMishi Rewards Program account holders. Join to earn reward points on every dollar you spend at mishimoto.com. Click here for our terms and conditions.
- Direct fit for the 2018-2023 Ford Mustang GT
- Single can mounts in line with the PCV system to separate oil from air using a 50 micron bronze filter
- Installs in under 30 minutes
- Robust, application-specific bracket mounts the can in a serviceable location away from most intake and supercharger kits
- Catch can has a 2 oz. capacity for longer servicing intervals
- Silicone hoses include pre-attached stock-style, quick-disconnect fittings for a true plug-and-play install
- Billet 6061 aluminum sealed can
- Defends intake system and essential components from oil blow-by
- Helps maintain proper octane levels to reduce potential detonation
- Filter and can are fully serviceable
- Internal air diverter turbulates air longer to improve oil separation
- Mishimoto Lifetime Warranty
- Patent number US D884,760 S
Installation Difficulty: Easy
- Direct fit for the 2018-2023 Ford Mustang GT
- Single can mounts in line with the PCV system to separate oil from air using a 50 micron bronze filter
- Installs in under 30 minutes
- Robust, application-specific bracket mounts the can in a serviceable location away from most intake and supercharger kits
- Catch can has a 2 oz. capacity for longer servicing intervals
- Silicone hoses include pre-attached stock-style, quick-disconnect fittings for a true plug-and-play install
- Billet 6061 aluminum sealed can
- Defends intake system and essential components from oil blow-by
- Helps maintain proper octane levels to reduce potential detonation
- Filter and can are fully serviceable
- Internal air diverter turbulates air longer to improve oil separation
- Mishimoto Lifetime Warranty
- Patent number US D884,760 S
Product Description
TECH SPECS
| Applications | 2018-2023 Ford Mustang GT |
|---|---|
| Engine Codes | 5.0 Coyote Gen 3 |
| Chassis Codes | S550 |
| Installation Notes | 22 in-lbs (2.5NM) recommended for all worm-gear clamps. These clamps have an operating range of 18-27 in- 2-3NM. Do not exceed the maximum torque rating of 27 in-lbs (3NM). |
| Note | After installation, Mishimoto recommends checking the contents of the baffled catch cans every 1,000 miles until a baseline is established. Oil blow-by accumulation will vary with ambient temperatures and driving conditions. It is important that the contents of the can do not rise above the internal baffle. May not be direct fit with some S/C applications. |
Installation Guides
Purchase Includes
(1) Application-Specific Mounting Bracket
(2) Direct-Fit Hoses with Pre-Installed Factory Quick-Disconnect Fittings
(2) 1/2-in Aluminum Barbed Fittings
(2) Worm Gear Clamps
Mounting Hardware
Mishimoto Lifetime Warranty
Note:
The automotive world never stands still, both literally and figuratively. Technology is always improving and evolving to produce mountains of power with maximum efficiency. Back during the Mustang's inception, all it took was a massive V8 and just enough traction to make it to the finish line in order to blow your socks off. These days, however, drivers want a muscle car that can do more than flex. They want it to be flexible. With over 50 years of engineering, Ford has been able to outrun most issues that keep their Mustang confined, except one"blow-by.
In 2015, Ford brought us the most modern Mustang yet. It was a familiar 5.0L powerplant, but we finally saw some much needed 21st century touches, like independent rear suspension for example. Ford went even further with the 2018
In our last two posts we took a look at the prototype catch can brackets and hoses for both the driver and passenger-side. As a recap and to better explain our results, the next paragraph describes the crank case ventilation systems on the Mustang GT. If you're not in a reading mood feel free to continue to the results below.
Crank Case Ventilation on the Mustang GT
While we can continue to refer to the two catch can systems as the driver and the passenger-side, we can also differentiate them another way. This will allow us to better understand the results of our testing. The passenger-side catch can is tapped into the ventilation line that allows crankcase air (and blow-by) to exit the engine. We often call this the positive crankcase ventilation, or PCV line. This line is equipped with a valve, referred to as the PCV valve, which works to regulate the air flowing through the crank case ventilation (CCV) system. The driver-side catch can is tapped
Last time we took a look at the passenger-side catch can setup for our brand-new Mustang GT. We will still be making more improvements to our original design going forward, but the main location will stay the same. Now onto our driver-side catch can development!
Driver-side Mustang catch can bracket installed
Driver-side Mustang catch can installed
The driver-side catch can was a bit more difficult to place than the
The 2016 Mustang GT has arrived at Mishimoto, and we are wasting no time in developing products for Ford's newest version of the Pony car. We decided to begin with a version of our baffled oil catch can specifically designed to be direct-fit with the Mustang GT.
Stock Mustang Parts
You would be doing your Coyote a favor by installing some type of catch can for preventative maintenance. Some feel that a catch can is not a necessity until you introduce forced induction, which may be the case. On the other hand every ounce of blow-by collected in a catch can is an ounce that is not heading back into your intake to kill fuel mileage, buildup on valves, and increase the risk of detonation. To read more about the benefits of a catch
