Performance Aluminum Radiator, fits Porsche Cayenne 2003-2010

Name: Performance Aluminum Radiator, fits Porsche Cayenne 2003-2010
SKU: MMRAD-CAY-03
Price: 532.77 USD
Availability: InStock

$532.77

Regular Price $887.95

Free shipping on this product and on orders over $149.

$Login or create an account to earn 532 pts on this product.

Installation Difficulty: Hard

MISHI POINTS INFO

Get exclusive points discounts ONLY for #TeamMishi Rewards Program account holders. Join to earn reward points on every dollar you spend at mishimoto.com. Click here for our terms and conditions.

Installation Specs

Key Benefits

Direct-Fit Performance Radiator for 2003-2010 Porsche Cayenne
Single row 40mm core maximizes coolant flow area for optimal performance
Strutted tubes ensure the strength of the radiator for robust durability
OEM-style louvered fin design to enhance airflow and cooling
Curved header plate enhances the core geometry to support increased strength, better-brazed connection, and larger contact area
Expansion joints explicitly designed for Porsche performance, aiding in a reduction of stress on the radiator and extending the overall lifespan
The radiator has a 3.4L fluid capacity, allowing for more fluid cooling over stock
The unique fan shroud locking mechanism is constructed from billet aluminum to mimic stock mounting for ease of installation, unlike the commonly used thin sheet metal or plastic that historically cracks.
Updated thicker and stronger mounting points for the radiator, AC condenser, and transmission cooler
CNC-machined inlet and outlet for smooth airflow and sized to connect to OE-style hose fittings
Slotted magnetic drain plug makes services mess-free
Includes foam sealing for more efficient cooling and fitment.
Modifications are not needed, allowing for an easier installation process

See all benefits

Key Benefits

Direct-Fit Performance Radiator for 2003-2010 Porsche Cayenne
Single row 40mm core maximizes coolant flow area for optimal performance
Strutted tubes ensure the strength of the radiator for robust durability
OEM-style louvered fin design to enhance airflow and cooling
Curved header plate enhances the core geometry to support increased strength, better-brazed connection, and larger contact area
Expansion joints explicitly designed for Porsche performance, aiding in a reduction of stress on the radiator and extending the overall lifespan
The radiator has a 3.4L fluid capacity, allowing for more fluid cooling over stock
The unique fan shroud locking mechanism is constructed from billet aluminum to mimic stock mounting for ease of installation, unlike the commonly used thin sheet metal or plastic that historically cracks.
Updated thicker and stronger mounting points for the radiator, AC condenser, and transmission cooler
CNC-machined inlet and outlet for smooth airflow and sized to connect to OE-style hose fittings
Slotted magnetic drain plug makes services mess-free
Includes foam sealing for more efficient cooling and fitment.
Modifications are not needed, allowing for an easier installation process

Engineered specifically for the 2003-2010 Porsche Cayenne, Mishimoto's Direct-Fit Performance Radiator is ideal for optimal vehicle cooling. Its single-row 40mm core and 3.4L fluid capacity maximize coolant flow, while strutted tubes and OEM-style louvered fins enhance durability and airflow. A curved header plate and Porsche-specific expansion joints increase strength and longevity. Featuring a unique billet aluminum fan shroud lock, thicker mounting points, a CNC-machined inlet and outlet, and a slotted magnetic drain plug. No modifications are required for a hassle-free installation. This radiator delivers exceptional performance and durability without compromising on ease of use.

More Information
Overall Length (in)	36.38
Overall Width (in)	4.74
Core Length (in)	27.95
Core Height (in)	21.77
Core Thickness (in)	1.5748
Fluid Capacity (gal)	0.9
Rows	1
Inlet (in)	1.52
Outlet (in)	1.52
Drain Plug Thread Size	M12x1.5
DPI	2756
Material	Aluminum
Engine Codes	M4801, M5501, M02.2Y, M48.00, M4851, M4851S
Chassis Codes	PL71
Coolant Capacity	0.9

Installation Guide

(Size: 19.1 MB)

(1) Performance Aluminum Radiator
(2) O-Rings
Required Install Hardware
Mishimoto Lifetime Warranty
