Filtering Your 6.4L Coolant, Part 2: Final Prototype and Installation

February 05, 2015

Ford 6.4L Powerstroke Coolant Filtration Kit 2008-2010

# turbo, silicone, rollcoal, radiator, powerstroke, hose, featured, diesel, development, boost, 6.4l, #engineering

Interested in purchasing our 6.4L coolant filter kit? Check out our product page for more information!

Mishimoto Ford 6.4L Powerstroke Coolant Filter Kit

Final Prototype Bracket

Welcome back! Our final bracket prototype is in and ready for installation. Check it out!

Mishimoto 6.4L coolant filter bracket

This bracket is constructed from 1/8" steel and is powder coated for additional protection against damage from road debris. We overbuilt this unit to ensure longevity and optimal resistance against potential damage.

Check out the hardware we will be using to attach our housing to the bracket. This hardware is also powder coated to prevent corrosion.

Coolant filtration kit hardware

Next, we assembled our filter housing, filter, and bracket together.

Coolant filtration kit assembled

We then installed this system to ensure fitment on our test vehicle.

Coolant filtration kit installed

As you can see, we are using ball valves

Mishimoto Ford 6.4L Powerstroke Coolant Filter Kit

We mentioned in our 6.0L coolant filtration thread that we would be tackling the 6.4L as well. Let's take a look at some of the components our team has been putting together for the 6.4L kit.

Although the 6.4L does not seem to be as susceptible to buildups as is the 6.0L, a coolant filtration setup is certainly still a worthy investment in preventive maintenance.

So let's get started!

Filter Housing

We'll start with the filter housing. As mentioned in our 6.0L thread, we developed a housing with a wide range of adjustability that could be utilized for a variety of kits. This housing is shown below.
